Lotus Elise Series 1 - DASH2 PRO Installation Kit

Features Road and Race:

RPM scale and shiftlights - scale 0-5000 when water <50oC/0-8000 when water >50oC
Water temperature - with warning above 100oC
Oil pressure - With alarm less than 20psi when RPM is more than 2000
Fuel level - with low fuel warning when below 10 litres
Gear (calculated)
GPS data logging with data download via USB

Road Mode:

Odometer
Trip meter
Speed

Race Mode:

Time slip
Last lap time
Lap counter

Warning lights:

Left/right indicators
Main beam
Hand brake
Alternator
Fog lights

Button functions:

Up (in menu) and start/stop logging
Down
Menu
Trip reset (road mode), add lap marker (race mode)
Menu+add lap marker = Clear all lap/sector markers (race mode)
