AIM Data Protocol
The Following information is obtainable from this ECU:
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| RPM
| Engine RPM
| RPM
| VAR_0010
| 25 RPM
|
| Wheel Speed
| Aux 26
| Auxiliary 1
| VAR_2025
| 0.1 kph
|
| Oil Pressure
| Pressure 2
| Oil Pressure
| VAR_3501
| 0.1 kPa
|
| Oil Temperature
| Temperature 9
| Oil Temperature
| VAR_1008
| 0.1°C
|
| Water Temperature
| Temperature 8
| Water Temperature
| VAR_1007
| 0.1°C
|
| Fuel Pressure
| Pressure 3
| Fuel Pressure
| VAR_3502
| 0.1 kPa
|
| Battery Voltage
| Misc 3
| Battery Voltage
| VAR_4002
| 0.01 V
|
| Throttle Angle
| Angle 1
| Throttle Angle
| VAR_3000
| 0.1°
|
| Intake Manifold Pressure
| Pressure 5
| Boost Pressure
| VAR_3504
| 0.1 kPa
|
| Intake Charge Temperature
| Temperature 1
| Temperature 1
| VAR_1000
| 0.1°C
|
| Exhaust Temperature
| Temperature 17
| Exhaust 1 Temperature
| VAR_1016
| 0.1°C
|
| Lambda
| Misc 1
| Lambda 1
| VAR_4000
| 0.1 Lambda
|
| Fuel Temperature
| Temperature 25
| Aux 1
| VAR_1024
| 0.1°C
|
| Gear
| Aux 27
| Auxiliary 2
| VAR_2026
| 1
|
