Configuring for use with SPEEDBOX

When using the ANALOG8 with a SPEEDBOX, where the analogue inputs are set as a fixed channel, the ANALOG8 must be configured to ensure that the same channel names are not used.

Analogue channels 1, 2, 3 and 4 are set to output on channels 1, 2, 3 and 4. If the ANALOG8 is to be used the module configuration must be set up as per the image below.
