ECUType / MoTeCM1Series

MoTeC M1 Series

Supported ECUs

  • M130
  • M150
  • M170
  • M182
  • M190

Connections

The Connections for the M1 series ECUs depends on the model being used, find the connection information for all supported models below;

M130

Race Technology CAN High – M130 B17*
Race Technology CAN Low – M130 B18*

M150

Race Technology CAN High – M150 D17*
Race Technology CAN Low – M150 D18*

M170

Race Technology CAN High – M170 A40*
Race Technology CAN Low – M170 A31*

M182

Race Technology CAN High – M182 C24*
Race Technology CAN Low – M182 C31*

M190

Race Technology CAN High – M190 C24*
Race Technology CAN Low – M190 C31*

*Please Note – The connections listed above are connections for CAN 1 on all ECU models, some Models in the series have more than one CAN connection. In complex installations using multiple CAN buses, please ensure the correct connection is used.


ECU Configuration

The protocol used by Race Technology is the one output as standard by the M1 Series ECU, no configuration is required.


Channel Listing

With the interface working correctly, the following channels of data will be available.

ECU Name Race Technology message Race Technology Default name Race Technology VAR number Resolution
Engine Speed RPM RPM VAR_0010 1rpm
Throttle Position Aux 1 Throttle Position VAR_1000 0.1%
Oil Pressure Pressure 2 Oil Pressure VAR_3501 0.01bar
Boost Pressure Pressure 5 Boost Pressure VAR_3504 0.01bar
Coolant Temperature Temperature 8 Water Temperature VAR_1007 0.1°C
Oil Temperature Temperature 9 Oil Temperature VAR_1008 0.1°C
Air Temperature Temperature 2 Inlet Pre Turbo 1 VAR_1001 0.1°C
Gearbox Temperature Temperature 10 Gearbox Temperature VAR_1009 0.1°C
Exhaust temperature Temperature 17 Exhaust 1 Temp VAR_1016 0.1°C
Fuel Pressure Pressure 3 Fuel Pressure VAR_3502 0.01bar
Battery Voltage Misc 3 Battery Voltage VAR_4002 0.01v
Road Speed Misc 4 Speed From ECU VAR_4003 0.1kph

Note - Not all channels listed in the table(s) above may be available from your ECU. This can be dependent on the vehicle model & year of manufacture.
