Audi
Supported Models
- Audi A3 2nd series 2003 - 2012
- Audi A4 3rd series 2005 - 2008
- Audi TT 1st series 2001 - 2006
- Audi TT 2nd series 2006 - 2014
Connections
Race Technology CAN connections
Audi CAN connection cables can be found in different places: behind the instrument cluster, near the steering column, behind the fuse box or the glove box inside the main wiring loom. Regardless of the stock ECU installed on the car, colours of the cables you need to connect to are always the same, they are twisted
CAN low - Orange/brown
CAN High - Orange/black
ECU setup
No ECU setup or termination is required.
Channel listing
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| MO1_RPM
| RPM
| RPM
| VAR_0010
| 1 RPM
|
| T_WATER
| temperature 8
| coolant temp
| VAR_1007
| 1C
|
| TAIR
| temperature 3
| Inlet pre turbo 2
| VAR_1002
| 1C
|
| T_OIL
| temperature 9
| Oil temp
| VAR_1008
| 1C
|
| OIL_TEMP_2
| temperature 11
| Gearbox post cooler
| VAR_1010
| 1C
|
| T STEER
| temperature 25
| temperature 25
| VAR_1024
| 1C
|
| MO1_PEDAL
| Aux 1
| Throttle position
| VAR_2000
| 0.004
|
| BOOST
| pressure 5
| Boost pressure
| VAR_3504
| 10mb
|
| BRAKE_PRESS
| Aux 7
| Fuel inj 2 PW
| VAR_2006
| 0.1Bar
|
| V_WH_FL
| Aux 14
| Fuel inj 1 cut
| VAR_2013
| 0.1 km/h
|
| V_WH_FR
| Aux 15
| Fuel inj 2 cut
| VAR_2014
| 0.1 km/h
|
| V_WH_RL
| Aux 16
| Fuel inj 3 cut
| VAR_2015
| 0.1 km/h
|
| V_WH_RR
| Aux 17
| Fuel inj 4 cut
| VAR_2016
| 0.1 km/h
|
| STEER_ERR
| General variable 1
| General variable 1
| VAR_1250
| -
|
| SUP_POW_STEER
| General variable 2
| General variable 2
| VAR_1251
| 0.1%
|
| LIMITER
| General variable 3
| General variable 3
| VAR_1252
| -
|
| SHIFT_DOWN
| General variable 4
| General variable 4
| VAR_1253
| -
|
| SHIFT_UP
| General variable 5
| General variable 5
| VAR_1254
| -
|
| FAULT_LAMP
| General variable 6
| General variable 6
| VAR_1255
| -
|
| GE1_ACTIVE
| General variable 7
| General variable 7
| VAR_1256
| -
|
| GE2_SYNCDZ
| General variable 8
| General variable 8
| VAR_1257
| -
|
| ABS_OFF
| General variable 9
| General variable 9
| VAR_1258
| -
|
| ABS_OFF
| General variable 10
| General variable 10
| VAR_1259
| -
|
| ASR_ACTIVE
| General variable 11
| General variable 11
| VAR_1260
| -
|
| ABS_ACTIVE
| General variable 12
| General variable 12
| VAR_1261
| -
|
| ASR_MOM_SLOW
| General variable 13
| General variable 13
| VAR_1262
| 0.1%
|
| ASR_MOM_FAST
| General variable 14
| General variable 14
| VAR_1263
| 0.1%
|
| ASR_OFF
| General variable 15
| General variable 15
| VAR_1264
| -
|
| MO1_MO_M_EX
| General variable 16
| General variable 16
| VAR_1265
| 0.1%
|
| ENG_TORQ_LOSS
| General variable 17
| General variable 17
| VAR_1266
| 0.1%
|
