EMS Stinger and 8860
The data input rate from the ECU is set at 19200 baud, which is compatible with the Stinger ECU and some versions of the 8860 ECU.
| ECU Name
| Race Technology message
| Race Technology Default name
| Race Technology VAR number
| Resolution
|
| RPM
| Engine RPM
| RPM
| VAR_0010
| 0.1 Hz
|
| Intake Manifold Pressure
| Pressure 5
| Boost Pressure
| VAR_3504
| 1 mBar
|
| Throttle Position
| Aux 1
| Throttle Position
| VAR_2000
| 0.1%
|
| Air/Fuel Ratio 1
| Misc 1
| Lambda 1
| VAR_4000
| 0.1 Lambda
|
| Air/Fuel Ratio 2
| Misc 2
| Lambda 2
| VAR_4001
| 0.1 Lambda
|
| Intake Air Temperature
| Temperature 1
| Temperature 1
| VAR_1000
| 0.1°C
|
| Water Temperature
| Temperature 8
| Water Temperature
| VAR_1007
| 0.1°C
|
| Ignition Time
| Measured Time 1
| Fuel Inj 1 PW on
| VAR_2500
| 1 ms
|
| Injection Time
| Measured Time 2
| Fuel Inj 2 PW on
| VAR_2501
| 1 ms
|
| Staged Injection
| Aux 26
| Auxiliary 1
| VAR_2025
| 0.1%
|
| Battery Voltage
| Misc 3
| Battery Voltage
| VAR_4002
| 0.01 V
|
